XGI-D24A | LS | Input Module
This series covered Danfoss, Sick, hitachi, Keyence, Lenze, Novotechnik, Gefran, vexta Advantech, Azbil and so on.. more than dozens of world reputation brands..
Description
- Manufacturer : LS
- Product No. : XGI-D24A
- Product Type : Input Module
- Input point : 32 points
- Insulation method : Photo coupler insulation
- Rated input voltage : DC 24 V
- Rated input current : Approx. 4 mA
- Voltage range : DC20.4 ~ 28.8V (5% and lower ripple rate)
- On voltage/On current : DC 19V and higher / 3mA and higher
- Off voltage/Off current : DC 11V and lower / 1.7mA and lower
- Input resistance : Approx. 5.6 k?
- Insulation withstand voltage : AC560V ms/3 Cycle (altitude 2000m)
- Common method : 32 points / COM
- Current consumption : 50mA
- External connection method : 40 point connector
- Weight : approx. 0.1 Kg
- Shipping Weight : 1.5 Kg
