Description
- Manufacturer: Banner
- QS18VP6FF50Q8
- P/N 71755
- WORLD-BEAM QS18 Series: Fixed-Field
- Range: 50 mm; Input: 10-30V dc
- Output: Complementay Solid State PNP
- Euro-Style Quick-Disconnect Connector
- Sensing Mode : Background Suppression (Fixed)
- Sensing Mode (General) : Proximity
- Sensing Mode (Specific) : Background Suppression (Fixed)
- Sensing Beam : Visible Red LED
- Max Sensing Range (mm) : 50
- Supply Voltage : 10-30 V dc
- Output Type : PNP
- Output response time (ms) : 0.85
- Delay at Power-up (ms) : 100
- Repeatability (?s) : 160
- Connection : Integral QD
- Number of Pins : 4
- IP Rating : IP67
- NEMA Rating : NEMA 6
- Min Op. Temp. (°C) : -20
- Max Op. Temp. (°C) : 70
- Maximum Op. Relative Humidity (%) : 95% @ 50°C
- Basic Housing Material : Thermoplastic
- Housing Style : Rectangular with M18 Barrel
- Lens Material : Acrylic
- Barrel Diameter (mm) : 18
- Audible Alarm : No
- Indicator : LEDs
- Remote Teach : No
- Clear Object Detection : No
- Intrinsically Safe : No
- Stainless Steel : No
- Timing (Hold/Delay) : No
- Washdown (IP68+) : No
- Water Detection : No
- Quick Disconnect Type : M12 (Euro)
- Ecolab Certified : No
- Shipping Weight : 1.1 Kg
