Pro-Face PFXSP5700TPD+PFXSP5B10 Touch Screen HMI + HMI Enclosure
Pro-face is a pioneer in HMI, providing industrial IoT solutions such as high-performance industrial computers, advanced HMIs, standard HMIs, basic HMIs and data collectors
Description
- Manufacturer : Pro-Face
- Part Number : PFXSP5700TPD+PFXSP5B10
- Family : HMI
- Series : SP5000 Series
- PFXSP5700TPD :
- Size : 15″
- Model / Global Code : PFXGP4115T3D
- Product Features : 15″ DC Auto Scaling Brightness Sensor (Premium Display)
- Display type : TFT Color LCD
- Display size : 15″
- Resolution : 1,024 x 768 pixels (XGA)
- Effective display area : W304.1 x H228.1 mm [W11.97 x H8.98 in.]
- Display colors : 16 million colors
- Backlight : White LED
- Backlight service life : 50,000 hrs. or more
- Brightness control : 0 to 100 (Adjusted with touch panel or software)
- Touch panel type : Resistive Film (analog, multi-touch)
- Touch panel resolution : 1,024 x 1,024
- Touch panel lifetime : 1,000,000 times or more
- Rated input voltage : 12 to 24 Vdc
- Input voltage limits : 10.8 to 28.8 Vdc
- External dimensions : W397 x H296 x D67 mm [W15.6 x H11.7 x D2.64 in.]
- Panel cut-out dimensions : W383.5 x H282.5 mm [W15.10 x H11.12 in.] | Panel thickness area: 1.6 to 5 mm [0.06 to 0.2 in.]*2
- Weight : 4.5 kg [9.93 lb] or less*3
- PFXSP5B10 :
- Size : Box (Power)
- Model / Global Code : PFXSP5B10
- Product Features : Box Module High-speed processing (Power Box)
- 12 Vdc (Supply from Display Module or DC Power Supply Adapter for Box Module “PFXZCDADEXP1”)
- Power consumption : Max. 25 W | When power is not supplied to external devices: 12.5 W or less*1
- Noise immunity : Noise Voltage : 1,000 Vp-p | Pulse Duration : 1 µs | Rise Time : 1 ns | (via noise simulator)
- External dimensions : W188 x H131 x D35 mm [W7.40 x H5.16 x D1.38 in.]
- Weight : 0.9 kg [1.98 lb] or less*1
- Shipping weight : 10 Kg
