Pro-Face PFXGP4502WADW HMI
Pro-face is a pioneer in HMI, providing industrial IoT solutions such as high-performance industrial computers, advanced HMIs, standard HMIs, basic HMIs and data collectors
Description
- Manufacturer : Pro-Face
- Part Number : PFXGP4502WADW
- Family : HMI
- Series : GP4000E Series
- Size : 10″ Wide
- Model : PFXGP4502WADW
- Global Code : PFXGP4502WADW
- Display type : TFT Color LCD / Resistive Film (analog)
- Display size : 10.1″ Wide
- Resolution : 640 x 480 pixels (WVGA)
- Effective display area : W219.6 x H131.76 mm [W8.645 x H5.187 in.]
- Display colors : 65,536 colors
- Backlight : LED
- Backlight service life : 20,000 hrs. or more
- Brightness control : 8 Levels (Adjusted with touch panel)
- Touch panel type : Resistive Film (analog)
- Touch panel lifetime : 1,000,000 times or more, Sweeping 100,000 times or more
- Rated input voltage : 24 Vdc
- Allowable voltage drop : 1 ms or less with lowest input voltage, 10 ms or less with rated input voltage
- Power consumption : 10 W or less
- In-rush current : 50 A or less*1
- Cooling method : Natural air circulation
- External dimensions : W275 x H206 x D38.2 mm [W10.83 x H8.11 x D1.5 in.]
- Weight : 0.56 kg [1.235 lb]
- Shipping weight : 8 Kg
