Parker DLD13M04R Digital servoamplifier
This series covered Danfoss, Sick, hitachi, Keyence, Lenze, Novotechnik, Gefran, vexta Advantech, Azbil and so on.. more than dozens of world reputation brands..
Description
Parker DLD13M04R Digital servoamplifier
This reference servoamplifier DLD13M04R and PARKER SSD PARVEX is a servo drive from the DIGIVEX series.
DLD13M04R : 230V single phase 50/60Hz, 4A/8A, 750W
This PARKER SSD PARVEX digital servoamplifier is at your disposal to replace your defective equipment and has a suitable guarantee.
This servo drive is 100% tested with an NX servomotor.
The DLD is ideal for low power applications where small footprint and precise speed control are required.
Combined with NX servomotors, it is a powerful and economical servo system solution.
230 Vac direct supply
Integrated EMC filter
Integrated braking
compactness
7-segment diagnostic display
Easy setup with Parvex Motion Explorer
DLD
Input/output
2- Analog inputs (14 bits and 10 bits, ± 10V diff.)
2- Analogue outputs (± 10V), configurable
5- Optocoupled logic inputs
3- Optocoupled logic outputs
Resolver input
230Vac auxiliary input
Incremental encoder emulation output
