IXP2-1200A | LS | Human Machine Interface XGT Panel
This series covered Danfoss, Sick, hitachi, Keyence, Lenze, Novotechnik, Gefran, vexta Advantech, Azbil and so on.. more than dozens of world reputation brands..
Description
- Manufacturer : LS
- Part Number : IXP2-1200A
- Display type : TFT color LCD
- Screen size : 12.1″
- Display resolution : 1,024*768
- Color indication : 24-bit color (16.7M colors)
- Backlight : LED method, automatic On / Off support
- Backlight lifetime : 40,000 hour
- Touch panel : Capacitive touch
- Audio output : Magnetic buzzer (85dB)
- Processor : 1GHz, Dual core
- Memory :
- Flash : 1GB
- Operating RAM : 1GB
- Backup RAM : 1 Mbyte
- Battery : CR2032(3.0V/210mAh, About 3years/25°C )
- Video output : 1*HDMI
- Ethernet : 1*10Base-T / 100Base-TX, 1?10Base-T / 100Base-TX / 1000Base-T
- USB host : 3*USB 2.0 (Front?1, Rear?2)
- USB device : 1*USB 2.0 (Send / Receive front, PC and project data etc.)
- Multi-language : Can display 12 languages simultaneously
- Animation : GIF format support
- Dimensions (mm) : 313*239*60
- Panel cut (mm) : 301.5*227.5
- Power iXP2-xxxxA : AC100 / 240V, iXP2-xxxxD : DC24V
- Weight (Kg) : 3.0
- Shipping Weight : 4 Kg
