Description

• Manufacturer : Bussmann
• Part Number : 170M5068
• Series : 170M Type TN 80
• Product Name : Eaton Bussmann Series High Speed Square Body Fuse
• Model Code : FUSE 1250A 600V 2TN/80 AR UC
• Type : Fuse
• Application : Semiconductor, DC Common bus, DC drives, power
• converters/rectifiers
• Amperage Rating : 1250 A
• Breaking capacity : 200 kA
• Fuse indicator : Top fuse status indicator
• Insulated metal gripping lugs (IMGL) : No
• Utilization category : aR (accompanied semiconductor protection)
• Voltage type : AC
• Fuse size : 2
• Rated voltage AC : 600 V
• Center-to-center distance of connections : 78 mm
• Current type : AC
• Mounting dimension : M10
• Class : Class aR
• Clearing (I2T) : 2400000 at 660 V
• Watt losses : 130 W
• Clearing loss : 130
• Fuse shape : Square body, slotted center bolted tags
• Pre arc (I2T) : 365000
• Color : None
• Interrupt rating : 200 kAIC
• Connection : Blade end x blade end
• Construction size : 2
• Packaging type : Standard
• Voltage rating : 600 Vac
• Fuse type : DIN 43653 | TN/80 Type T Indicator for Micro
• Fuse system (according to IEC 60269) : Other
• Certifications : IEC Rated | UL Recognized
• Product Length/Depth : 286 mm
• Product Height : 66 mm
• Product Width : 165 mm
• Product Weight : 594 g
• Shipping Weight : 1.2 Kg
