B&R X20DIF371 I/O module
B&R is a professional industrial automation solutions provider, offering products and services for the total automation of machinery and equipment, scalable software and hardware
Description
- Manufacturer : B&R
- MATERIAL NUMBER: X20DIF371
- 16 digital inputs
- Source circuit
- 1-wire connections
- Configurable software input filter for entire module
- The module is equipped with 16 inputs for 1-wire connections. The module is designed for sink input wiring.
- I/O module : 16 digital inputs 24 VDC for 1-wire connections
- B&R ID code : 0xC0E8
- Status indicators : I/O function per channel, operating state, module status
- Module run/error : Yes, using LED status indicator and software
- Bus : 0.18 W
- Internal I/O : 1.47 W
- Additional power dissipation caused by actuators (resistive) [W] : –
- Horizontal : Yes
- Vertical : Yes
- Installation elevation above sea level : 0 to 2000 m : No limitation
- Installation elevation above sea level : >2000 m : Reduction of ambient temperature by 0.5°C per 100 m
- Degree of protection per EN 60529 : IP20
Horizontal mounting orientation : -25 to 60°C
- Vertical mounting orientation : -25 to 50°C
- Derating : See section “Derating”.
- Storage : -40 to 85°C
- Transport : -40 to 85°C
- Relative humidity Operation,Storage & Transport : 5 to 95%, non-condensing
- Note : Order 1x terminal block X20TB1F separately. Order 1x bus module X20BM11 separately.
- Pitch : 12.5+0.2mm
- Shipping Weight : 2 Kg
