B&R Analog Input Module X20AI2322

B&R is a professional industrial automation solutions provider, offering products and services for the total automation of machinery and equipment, scalable software and hardware

B&R

Description

Manufacturer : B&R
Product No. : X20AI2322
Product Type : X20 Analog Input Module
I/O module : 2 analog inputs 0 to 20 mA / 4 to 20 mA
Power consumption
Bus : 0.01 W
Internal I/O : 0.8 W
Input : 0 to 20 mA/4 to 20 mA
Input type : Differential input
Digital converter resolution : 12-bit
Conversion time : 300 µs for all inputs
Output format
- Data type : INT
- Current : 0x0000 – 0x7FFF / 1 LSB = 0x0008 = 4.883 µA
Load : <400 Ω
Input protection : Protection against wiring with supply voltage
Permissible input signal : Max. ±50 mA
Output of digital value during overload : Configurable
Conversion procedure : SAR
Input filter : 3rd-order low pass / cutoff frequency 1 kHz
Electrical isolation :
- Channel isolated from bus
- Channel not isolated from channel
Shipping Weight : 2.5 Kg
