BANNER SMA31EQD Emitter Mini Beam
This series covered Danfoss, Sick, hitachi, Keyence, Lenze, Novotechnik, Gefran, vexta Advantech, Azbil and so on.. more than dozens of world reputation brands..
Description
- Manufacturer: Banner
- SMA31EQD
- P/N 26842
- Contact a Banner Engineer About Your Application
- MINI-BEAM: Emitter
- Range: 3 m; Input: 24-240V ac
- Output: Not applicable – No outputs
- Quick-Disconnect Connector
- Sensing Mode (General): Opposed
- Sensing Beam: Infrared LED
- Opposed Mode Emitter/Receiver: Emitter
- Max Sensing Range [m]: 3
- Supply Voltage: 24-240 V ac
- Output Type: Solid-State AC Switch
- Operation: Light/Dark Operate
- Output response time [ms]: 2 ON/1 OFF
- Delay at Power-up [ms]: 300
- Repeatability (µs): 300
- Connection: Integral QD
- Number of Pins: 3
- IP Rating: IP67
- NEMA Rating: NEMA 1, 2, 3, 3S, 4, 4X, 6, 12, 13
- Min Op. Temperature [°C]: -20
- Max Op. Temperature [°C]: 70
- Max Op. Relative Humidity [%]: 90% @ 50°C
- Basic Housing Material: Thermoplastic
- Housing Style: Rectangular with M18 Barrel
- Lens Material: Acrylic
- Adjustments: Potentiometer
- Barrel Diameter [mm]: 18
- Shipping Weight: 1 Kg
