Description

• Manufacturer: Balluff
• Order code: BES 516-363-S4-C
• Housing Size: M30

• Housing material: CuZn, nickel plated

• Sensing face material: PA 12

• Mounting: non flush mountable

• Number of Wires: 3-wire

• Switching output: NPN

• Switching element function: NO

• Rated operating distance (sn): 15 mm

• Assured operating distance: 0…12.2 mm

• Rated operational voltage (Ue): 24 DC V

• Supply voltage max. (Ub): 30 V

• Supply voltage min. (Ub): 10 V

• Voltage drop max. static: 2.5 V

• Load current capacity (Ie): 200 mA

• Short circuit protected: yes

• Protected against polarity reversal: yes

• Output indication: yes

• Ambient temperature min: -40 °C

• Ambient temperature max: +85 °C

• Operating frequency (f): 100 Hz

• Degree of protection IP: IP68 per BWN Pr 20

• Insulation class: 2

• Connection: Connector S4 (M12)

• Approval: CE,ULZ1

• Off-state current max (Ir): 80 µA

• Repeat accuracy max. (R): 5 %

• Electrical type: DC

• Shipping Weight: 1 kg
