2A 500-30 H3 | AEG | THYRO-A Digital Thyristor SCR Power Controllers
This series covered Danfoss, Sick, hitachi, Keyence, Lenze, Novotechnik, Gefran, vexta Advantech, Azbil and so on.. more than dozens of world reputation brands..
Description
- Manufacturer : AEG
- 2A 500-30 H3
- 2A -Thyro-A : 2-phase version for 3-phase load in cost saving 3-phase circuit; operating mode: TAKT
- 500 – Rated Voltage …H 3 : 500 V -57% +10%
- 30 -Rated Current
- Load Types
Types Ohmic loads employed at Rwarm/Rcold ratio 6:1
Limitation of on 3 x Inom
- Transformer loads
Network Load Internal network load optimization for the operating modes QTM and TAKT
Interface for external network load optimization available, e.g. Thyro-Power Manager
- H3-Functional Features : Set point inputs :
- 2 set point inputs, secured (SE LV, PE LV) from the mains
- Input of analog set point, signal intervals: 0(4)-20 mA, 0(1)-5 V, 0(2)-10 V
- Control input for switch operation mode – dual point Control is possible (UOn = 3 to 24 V) digital set point is provided by the process computer or bus system
- Dimensions WxHxD(mm) : 45 x 136 x 129
- Approx.Weight (kg) : 0.7
- Shipping Weight : 3 Kg
