2866734 QUINT-PS/3AC/24DC/ 5 | PHOENIX | Power supply unit
This series covered Danfoss, Sick, hitachi, Keyence, Lenze, Novotechnik, Gefran, vexta Advantech, Azbil and so on.. more than dozens of world reputation brands..
Description
- Manufacturer: Phoenix
- Product Number: 2866734
- Product Type: Power Supply Unit
- Nominal input voltage range: 3x 400 V AC … 500 V AC
- Input voltage range: 3x 320 V AC … 575 V AC, 2x 360 V AC … 575 V AC, 450 V DC … 800 V DC
- Voltage type of supply voltage: AC/DC
- Inrush current: < 15 A (typical)
- Inrush current integral (I2t): < 1 A2s
- AC frequency range: 45 Hz … 65 Hz
- Frequency range DC: 0 Hz
- Mains buffering time: > 20 ms (400 V AC), > 30 ms (500 V AC)
- Current consumption: 3x 0.8 A (400 V AC), 3x 0.7 A (500 V AC), 0.2 A (600 V DC)
- Nominal power consumption: 268 VA
- Protective circuit: Transient surge protection; Varistor, gas-filled surge arrester
- Power factor (cos phi): 0.5
- Typical response time: < 0.06 s
- Permissible backup fuse: B6 B10 B16 AC:
- Permissible DC backup fuse: DC: Connect a suitable fuse upstream
- Recommended breaker for input protection: 6 A … 16 A (AC: Characteristics B, C, D, K)
- Discharge current to PE: < 3.5 mA
- Shipping Weight: 2 kg
