2866721 QUINT-PS/1AC/12DC/20 | PHOENIX | Power Supply Unit
This series covered Danfoss, Sick, hitachi, Keyence, Lenze, Novotechnik, Gefran, vexta Advantech, Azbil and so on.. more than dozens of world reputation brands..
Description
- Manufacturer: Phoenix
- Product Number: 2866721
- Product Type: Power Supply Unit
- Nominal input voltage range: 100 V AC … 240 V AC
- Input voltage range: 85 V AC … 264 V AC, 90 V DC … 350 V DC (UL 508: = 250 V DC)
- Input voltage range AC: 85 V AC … 264 V AC
- Input voltage range DC: 90 V DC … 350 V DC (UL 508: = 250 V DC)
- Electric strength, max.: 300 V AC
- Voltage type of supply voltage: AC/DC
- Inrush current: < 20 A (typical)
- Inrush current integral (I2t): < 3.2 A2s
- AC frequency range: 45 Hz … 65 Hz
- Frequency range DC: 0 Hz
- Mains buffering time: typ. 40 ms (120 V AC), typ. 40 ms (230 V AC)
- Current consumption 1.2 A (220 V DC), 2.4 A (120 V AC), 1.4 A (230 V AC), 2.5 A (110 V DC)
- Nominal power consumption: 311 VA
- Protective circuit: Transient surge protection; Varistor
- Typical response time: < 1 s
- Input fuse: 12 A (slow-blow, internal)
- Permissible backup fuse: B10 B16 AC:
- Permissible DC backup fuse: DC: Connect a suitable fuse upstream
- Recommended breaker for input protection: 10 A … 16 A (AC: Characteristics B, C, D, K)
- Discharge current to PE: < 3.5 mA
- Shipping weight: 3.5kg
