Description
- Manufacturer : Phoenix
- Product No. : 2866718
- Product type : QUINT-PS/1AC/12DC/15 Power Supply Power Supply Unit
- Nominal input voltage: 100 V AC … 240 V AC
- AC input voltage range: 85 V AC … 264 V AC
- DC input voltage range: 90 V DC … 350 V DC (UL 508: = 250 V DC)
- Electric strength, max: 300 V AC
- Voltage type of supply voltage: AC/DC
- Inrush current: < 15 A (typical)
- Inrush current integral (I^2t): < 1.5 A^2s
- AC frequency range: 45 Hz … 65 Hz
- Frequency range DC: 0 Hz
- Mains buffering time: > 65 ms (120 V AC), > 65 ms (230 V AC)
- Current consumption: 1.9 A (120 V AC), 0.9 A (230 V AC), 1.9 A (110 V DC), 0.9 A (220 V DC)
- Nominal power consumption: 210 VA
- Protective circuit: Transient surge protection; Varistor
- Typical response time: < 0.5 s
- Input fuse: 6.3 A (slow-blow, internal)
- Permissible backup fuse: B10 B16 AC:
- Permissible DC backup fuse DC: Connect a suitable fuse upstream
- Recommended breaker for input protection: 10 A … 16 A (AC: Characteristics B, C, D, K)
- Discharge current to PE: < 3.5 mA
- Shipping Weight : 2.5 Kg
