2320911 QUINT-PS/1AC/24DC/10/CO | PHOENIX | Power supply
This series covered Danfoss, Sick, hitachi, Keyence, Lenze, Novotechnik, Gefran, vexta Advantech, Azbil and so on.. more than dozens of world reputation brands..
Description
- Manufacturer: Phoenix
- Product Number: 2320911
- Product Type: Power supply, with protective coating
- Nominal input voltage range: 100 V AC … 240 V AC, 110 V DC … 250 V DC
- Input voltage range: 85 V AC … 264 V AC, 90 V DC … 410 V DC +5 % (UL 508: = 250 V DC)
- Input voltage range AC: 85 V AC … 264 V AC
- Input voltage range DC: 90 V DC … 410 V DC +5 % (UL 508: = 300 V DC)
- Electric strength, max.: 300 V AC
- Voltage type of supply voltage: AC/DC
- Inrush current: < 15 A
- Inrush current integral (I2t): < 1.5 A2s
- AC frequency range 50 Hz … 60 Hz
- Mains buffering time typ. 36 ms (120 V AC), typ. 36 ms (230 V AC)
- Current consumption: 4 A (100 V AC), 1.7 A (240 V AC), 2.2 A (120 V AC), 1.3 A (230 V AC), 2.5 A (110 V DC), 1.2 A (220 V DC), 3.4 A (110 V DC), 1.5 A (250 V DC)
- Nominal power consumption: 303 VA
- Protective circuit: Transient surge protection; Varistor, gas-filled surge arrester
- Typical response time: < 0.15 s
- Input fuse: 10 A (slow-blow, internal)
- Permissible backup fuse: B10 B16
- Recommended breaker for input protection: 10 A … 20 A (AC: Characteristics B, C, D, K)
- Discharge current to PE: < 3.5 mA
- Shipping weight: 3 kg
