170M6221 | Bussmann | Eaton Bussmann Series High Speed Square Body Fuse
-
Manufacturer : Bussmann
-
Part Number : 170M6221
-
Product Name : Eaton Bussmann Series High Speed Square Body Fuse
-
Model Code : FUSE 2000A 550V 3TN/110 AR UR
-
Type : Fuse
-
Application : Semiconductor, DC Common bus, DC drives, power
-
converters/rectifiers
-
Amperage Rating : 2000 A
-
Breaking capacity : 200 kA
-
Fuse indicator : Top fuse status indicator
-
Insulated metal gripping lugs (IMGL) : No
-
Utilization category : aR (accompanied semiconductor protection)
-
Voltage type : AC
-
Fuse size : 3
-
Rated voltage AC : 550 V
-
Center-to-center distance of connections : 108 mm
-
Current type : AC
-
Mounting dimension : M10
-
Class : Class aR
-
Clearing (I2T) : 6350000 at 660 V
-
Watt losses : 175 W
-
Clearing loss : 175
-
Fuse shape : Square body, slotted center bolted tags
-
Pre arc (I2T) : 370000
-
Color : None
-
Interrupt rating : 200 kAIC
-
Connection : Blade end x blade end
-
Construction size : 3
-
Packaging type : Standard
-
Voltage rating : 550 V AC
-
Fuse type : DIN 43653 | TN/110 Type T Indicator for Micro | Bolted tag
-
Fuse system (according to IEC 60269) : Other
-
Product Length/Depth : 168 mm
-
Product Height : 76 mm
-
Product Width : 95 mm
-
Product Weight : 1229 g
-
Shipping Weight : 3 Kg
